GI-600PB Ultrasonic Fuel Injector Cleaner & Tester

Description

GI-600PB is an ultrasonic piezo injector cleaner & tester equipment. It is a mechatronic product that combines ultrasonic cleaning technology with microprocessor fuel pressure control cleaning and testing technology. It supports GDI, Piezo, Traditional and motorcycle Injectors. The fuel injector cleaner machine can comprehensively evaluate the performance of the fuel injector, ensuring that its cleanliness and working condition are at the optimal level.

Features

High-efficiency Ultrasonic Cleaning Technology

The GI-600PB Injector cleaner & tester equipped with 100W ultrasonic cleaning power and a 2000ml large-capacity fuel tank, can completely remove carbon deposits, colloids and other sediments inside the injector. The ultrasonic wave with the high-frequency vibration can penetrate into the tiny pores to finish dead-angle cleaning, significantly improving the atomization effect and fuel efficiency of the injector.

High-precision Resistance & Wide-range Simulated Test

With 0.1ΩResistance test accuracy, the GI-600PB injector cleaner machine can quickly detect the resistance value of the injector coil to determine the real situation: short circuit, open circuit or aging problems, ensuring that the circuit system works normally, and avoid injection failures caused by abnormal resistance. And this injector cleaner supports 100~9900rpm(step: 10rpm) RPM range and 0.1~25ms(step: 0.1ms) pulse width, which can accurately simulate the injector working state under different working conditions of the engine.

Wide Range of Adaptations

This GI-600PB fuel injector testing equipment has a wide range of adaptations and can clean and test piezo fuel injectors, GDI injectors, traditional injectors, as well as motorcycle fuel injectors.

Flexible Pressure and Time Control

This fuel injector cleaner & tester provides a working pressure of 0-10 bar adjustment range to meet the testing needs of various injectors(such as Piezo, GDI, EFI, SFI). And by setting the time from 5~300 seconds (step: 5 seconds), users can flexibly adjust the cleaning or test time according to actual needs to improve operating efficiency.

Safe and Reliable Multi-power Compatible Design

The fuel injector ultrasonic cleaner supports two voltage inputs: AC220V±10% 50Hz/60Hz or AC110V±10% 60Hz, and adapts to the electricity standards of different regions. And the injector cleaner in this model is equipped with 300W stable power output, ensuring that the equipment remains stable and safe during long-term work.

With Storage Drawer in Special Design

This car injector cleaner machine is equipped with special-design storage drawer, it’s suitable for automobile repair shops, professional fuel system maintenance institutions, etc. Its multifunctional integrated design not only saves working time, but also significantly improves maintenance accuracy, extends the injector’s service life, and brings higher economic benefits to customers.

Specifications
